Details

• Whisper-quiet direct-current linear motors
• IP54-approved electrical components protected from dust and water infiltration
• 2 receptacles for IV holder stems
• Battery ensuring temporary autonomous operation
• Casters equipped with individual brakes
• Possibility of moving the bed at any heights even when in its lowest position
• Metal surfaces covered with electrostatic powder paint
• Manually adjustable foot section angle (choice of two positions : flexion and standard)
• Bed designed for home care patients or long-term care facilities
• Authentic Canadian product

Specifications

Load capacity : 500 lbs (227 kg)

Available dimensions :

• 36” X 75” or 80” (91 x 191 or 203 cm)
• 39” X 75” or 80” (99 x 191 or 203 cm)
• 48” X 75” or 80” (122 x 191 or 203 cm)

Minimum height : 12″ (30,5 cm)

Maximum height : 30″ (76,2 cm)

Maximum backrest angle : ~ 70° (degrés)

Maximum footrest angle : ~ 40° (degrés)

Bed weight : 209 lb (95 kg)

Recommended mattress height : 5″ (12,7 cm)

Accessories

• Melamine decorative headboard and footboard (Choice of colors : white, rosewood, maple)
• Composite decorative headboard and footboard
• rotating half side rails
• rotating half side rails with increased protection height
• tilt-up half side rails 28”
• tilt-up half side rails 23”
• Metallic half side rails
• full side rails
• Metallic support with bar and trapeze
• Trolley for beds

Options

• Digital nurse control integrated in the footboard
• Digital patient control integrated in the side rails
• Central brake system
• Composite platform
• Bed length extension to 84” (213 cm)
• Extensions to increase the clearance underneath the bed of 1” or of 2” (2,5 or 5 cm)

Warranty

• 20 years on the frame
• 2 years on the electric motors
• 2 years on the hand control and electronic components
• 1 year on the accessories and against any fabrication defect
